will show you furthermore applications about this op-amp in the future.DUAL OPERATIONAL AMPLIFIERS.

This is the concept all about this popular and rare IC which is easy to use.

Two operational amplifiers are compensated internally.

When the piezo sensor is triggered, then the output of the sensor goes high and activates the Schmitt trigger. When the piezo sensor is not activated, the output of the sensor will be low. LM358 is connected as an inverting Schmitt trigger. In this circuit, a piezoelectric sensor is used as a sensor, that has to fix where you need to install it. The application of this circuit is an anti-theft alarm.

LM358 IC-based Shock Alarm Circuit: Another popular LM358 IC-based circuit is a shock alarm circuit that is used for home to automobiles. In the circuit, If the light stops falling on the LDR, then the IC turns on the LED immediately. LM358 IC-based Dark Sensor Circuit: This darkness detector sensor operates with the principle of IC LM358 with a Light Dependent Resistor (LDR).

The power supply voltage and differential input voltages are similar.

Common-mode input voltage range comprises the ground.

The supply current drain is very low, 500 μA.The range of dual power supplies is (+/-) 1.5V to (+/-) 16V.The range of a single power supply is 3V to 32V.

The range of wide power supplies includes a single and dual power supply.
